Hey friends!

What Kind of V8 Engines You Want Best?

Your answers will be helpful for we EngineDIY Team to produce various V8 engines. It is much appreciated if you could do us a favor to fill the survey! There is a coupon code for you after finishing the survey. Thank you in advance!

Click here to finish the survey!

Wanna Know TOYAN V8 Engine Price? Click Here!
At What Price Do You Accept For TOYAN V8 Engine?
Please comment.

More Updates about TOYAN V8 Engine

1. DIY Fun
Made of highly precise parts
Assemble inline with the instructions
To walk deeply through the mechanical principle

toyan v8 engine

2.High Simulation Miniature
Designed with red sports elements Highly authentic appearance1:10 scale realistic engine

Basic Parameters:
·Displacement: 3.5ccx8
·Bore:16.67mm
·Stroke: 17.00mm
·RPM:1800-12500rpm
·Power:4.35ps@11200rpm
.Weight:2.05kg

toyan v8 engine

3.Long Stroke
The cross crankshaft is the blueprint for the engine design, effectively providing higher torque. Customized flexible oil seal keeps sealing performance in high speed operation.

4. Mechanical water cooling pump
The power of the pump, come from the crankshaft provides circulation power for the coolant liquid, and then in conjunction with the cooling fan to strengthen the self-cooling performance.

toyan v8 engine

5.Integrated Machining Crankshaft
Built with 90 degree cross crankshaft structure, the engine features smoother operation, increasingly sensitive acceleration response with the highest speed up to 12500 RPM.

6. Precise Rocker Arm
Independent Intake & Exhaust Design
More Accurate Valve Switch
Alloy Rocker Arm

toyan v8 engine

7.Dual Synchronous Pulley
The timing structure of the dual synchronous pulley minimizes the risk of gear jumping in high speed operation.

8. Precise Carburetor
The engine is designed with the brand new carburetor with pump for astoundingly accurate adjustment and superior response sensitivity of the throttle and more stable operation to users.

toyan v8 engine


9. Integrated Exhaust Pipe
The small all-metal exhaust manifold provide the engine a more vigorous and powerful sound.

10. Lightweight
The lightweight structure of the engine enables impressive compatibility with RC models and greatly improved output ratio of the unit power.

toyan v8 engine

11. Stereoscopic Cross-section Drawing

toyan v8 engine

12. Packing

toyan v8 engine

FAQ About TOYAN V8 Engine
Q1: Would you please share some basic information about this TOYAN V8 Engine?
A: There are 2 version for TOYAN V8 Engine, one is KIT and the other assembled. This V8 engine is in 1/10 scale and use nitro (methanol) fuel. (20-25% nitro fuel is prepared by user)

 Q2: How does this TOYAN V8 Engine lubricate?
A: About its lubrication method, it is the same to TOYAN FS-L400 Engine, that is to say, it adopts mixed splash lubrication instead of independent lubrication. Just add a small amount of grease to the camshaft.


Q3: Is it water cooling or air cooling?
This new TOYAN V8 Engine is water-cooled version due to the positioning is mainly desktop power and is based on TOYAN L400 4-cylinder engine. There is a built-in mechanical water-cooling pump and the power of the pump body comes from the crankshaft to provide circulating power for the coolant. (Water cooling accessories are prepared by user)

Q4: What's difference of the exhaust pipe of TOYAN V8 Engine?
There is a highlight of this TOYAN V8 Engine's exhaust pipe. It adopts full metal small integrated exhaust manifold which is welded instead of metal printed parts. And the process is quite difficult and it costs a lot to lower the defect rate.

Q5: Is there any new design for this TOYAN V8 Engine's carburetor ?
A: Certainly, the carburetor of TOYAN V8 Engine adopts a new carburetor with a pump that is completely different from TOYAN L400 Engine.

Q6: What's the crank structure about this TOYAN V8 Engine?
TOYAN V8 Engine adopts a 90-degree cross-crankshaft structure. You must know that performance machines generally use a straight-line crankshaft like Ferrari V8.

Q7: Is there any support for the crankshaft on TOYAN V8 Engine?
Sure, we did .
Pain point of crankshaft support - the crankshaft of TOYAN V8 adopts an integrated design, which is thickened, and there is a support point in the middle of the crankshaft to avoid the same mistakes as TOYAN L400 Engine.

Q8: Why methanol engine? I like gasoline engine better!
A: TOYAN V8 engine is powered by nitro but we are able to transfer it into the gasoline version. Because the side of the cylinder head adopts the D-axis extension and the OP upgrade parts will be lauched in the next future.

Q9: Any other color for option?
A:  TOYAN V8 Engine still adopts red and black which is recognizable color to TOYAN Engines. TOYAN V8 Engine may be in different colors in the next future. Which Color You Want Best?

Q10: Will there be a supercharger compatible with TOYAN V8 Engine?
A: As an OP upgrade, the supercharger is being designed now and will be launched soon after TOYAN V8 Engine being released.

Q11: What scale of rc car is the TOYAN V8 Engine suitable for?
A: According to the size of the engine, it is probably suitable for rc cars with a ratio of about 1/5 and 1/6.

Q12: The TOYAN V8 uses a single camshaft structure like the 4-cylinder engine. Will a V8 with a dual camshaft structure be launched in the future?
A: Yes, this TOYAN V8 adopts single camshaft structure. Even though it is not easy to make a V8 engine with a dual camshaft structure but several V8 Engine will be launched in the next future.
Let us know more your need!

Find more TOYAN Engine & Parts, please click here!

Discover more different V8 Engine Model on enginediy, please click here!

Kind Regards,

EngineDIY Team
